Derek UML2 Tutorials

Category: Business


Posted on 2019-01-07, by fubber.

Description


Derek UML2 Tutorials



General:

Welcome to my UML 2.0 Video Tutorial! In this series I will cover Use Case, Activity, Class, Object, Sequence and many more UML Diagrams.

Unified Modeling Language (UML) is a graphical way of describing software systems. In this tutorial, I�ll focus on Use Case Diagrams which list the steps a system needs to follow to reach a goal. I�ll walk you through the parts of a Use Case Diagram as well as the requirements of a Use Case Description.

It starts slow, but quickly it will dramatically improve your ability to create robust systems.
Example Use Case Description

Description

The user enters their card and PIN. Security verifies the card. The user selects the account to use. They select an amount. Security verifies if the amount is available. The system comes to a conclusion on if money is provided. The user selects funds as $10s or $20s. Security provides the funds if possible. Security provides a receipt and the users card.

Trigger

Machine receives a card
User enters a PIN

Actors

Customer
Bank Security

Preconditions

Secure Connection to Bank
Bank Has Cash

Goals (Successful Conclusion)

Secure Client Accounts
Provide Customer with Funds

Failed Conclusion

Invalid Card
Invalid PIN
Customer Insufficient Funds
ATM Insufficient Funds
Over Daily Limit
Stolen Card

Extensions (Alternatives)

If PIN is Invalid 3 Times (Eat Card)
If Card Marked as Stolen (Eat Card)

Steps of Execution (Requirements)

1. Customer Inserts Card
1A. Card is Invalid
1B. Eject Card
2. Card is Validated
3. Customer Enters PIN
3A. PIN is Invalid
3B. PIN is Invalid 3 Times
3C. Card Marked as Stolen
4. PIN is Validated
5. Account is Selected
6. Amount is Selected
6A. Over Daily Maximum
6B. Over Account Funds Available
6C. Over Funds in Machine
6D. Ask for New Amount
7. Provide $10 or $20
8. Provide Funds
Provide Receipt
10. Eject Card
